Packaging Dimension | (กxยxส) 35x25x50 ซม. |
Weight Detail | 12.1กก. |
Output
Output power capacity
540Watts / 900VA
Max Configurable Power (Watts)
540Watts / 900VA
Nominal Output Voltage
230V
Output Frequency (sync to mains)
50/60Hz +/- 3 Hz
Output Frequency (not synced)
50/60 Hz +/-1 Hz
Load Crest Factor
3 : 1
Topology
Line Interactive
Waveform type
Stepped approximation to a sinewave
Output Connections
(4) IEC 320 C13 (selector_surgetitle)
(2) IEC Jumpers (Battery Backup)
(4) IEC 320 C13 (Battery Backup)
Transfer Time
8ms typical : 10 ms maximum
Bypass
Built-in Bypass
Input
Nominal Input Voltage
230V
Input frequency
50/60 Hz +/- 3 Hz (auto sensing)
Input Connections
IEC-320 C14
Input voltage range for main operations
176 - 294V
Input voltage adjustable range for mains operation
156 - 300V
Number of Power Cords
1
Maximum Input Current
8.0A
Batteries & Runtime
Battery type
Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
Typical recharge time
8hour(s)
Replacement Battery
APCRBC123
Expected Battery Life (years)
3 - 5
RBC Quantity
1
Battery Volt-Amp-Hour Capacity
157
Runtime
View Runtime Graph
View Runtime Chart
Efficiency
View Efficiency Graph
Communications & Management
Interface Port(s)
Optional Simple Signalling RS232 cable , USB
Control panel
Multi-function LCD status and control console
Audible Alarm
Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
Surge Protection and Filtering
Surge energy rating
613Joules
Data Line Protection
Analog phone line for phone/fax/modem/DSL (RJ-11 connector), Network line - 10/100/1000 Base-T Ethernet (RJ-45 connector)
Filtering
Full time multi-pole noise filtering :10% of IEEE surge let-thgouh : zero clamping response time: instantaneous
Physical
Maximum Height
250mm , 25.0cm
Maximum Width
100mm , 10.0cm
Maximum Depth
382mm , 38.2cm
Net Weight
10.72kg
Shipping weight
11.7kg
Shipping Height
337mm , 33.7cm
Shipping Width
225mm , 22.5cm
Shipping Depth
487mm , 48.7cm
Color
Black
Master Carton Units
1.0
Pallet Dimensions
46inches
Pallet Weight
865.22lbs.
Units per Pallet
30.0
SCC Codes
1073130427959 1
Environmental
Operating Environment
0 - 40 ?C
Operating Relative Humidity
0 - 95 %
Operating Elevation
0-2952.6meters
Storage Temperature
-15 - 45 ?C
Storage Relative Humidity
0 - 95 %
Storage Elevation
0-14763.6meters
Audible noise at 1 meter from surface of unit
45.0dBA
Conformance
Approvals
A-tick, C-tick, CE, GS Mark
Equipment protection policy
Lifetime : 200000 AUD, Lifetime : 150000 Euros, Lifetime : 75000 GBP
Standard warranty
2 years repair or replace, 3 years repair or replace for European Union countries
Sustainable Offer Status
RoHS
Compliant
REACH
REACH: Contains No SVHCs
PEP
Available in Documentation tab
EOLI
Available in Documentation tab
รับประกัน 2Y carry in
*Default Warranty is 2years carryin, customer must fill FORM and submit together with NTT INV to extend +1yr carryin with Schneider by themselves (please see SAMPLE Form below tap)
